Meet the New TrafficJet™ Xpert

TrafficJet Xpert is built on the Mutoh XpertJet printer platform and optimized for traffic signage, work zone applications, and custom graphics. True Traffic Color™ spot inks and included software automates sign making, simplifying the printing of specification compliant traffic control, wayfinding, and custom signage.

At a Glance:

  • Faster printing and less ink consumption with integrated dryer
  • Simplified machine operation with new touchscreen panel
  • Reduced cartridge waste and increased capacity with large bulk ink loaders
  • Updated appearance with sleek black-on-black finish



Request a Quote    Request a Sample

Download Product Overview
Download Product Overview (Spanish)
Download Product Overview (Portuguese)

Print at 162 sq/ft per hour
Best cost-to-print speed ratio

New Features

  • Blazing fast print speeds with new integrated dryer

  • Simplified operation with new touch screen

  • Print longer and reduce cartridge waste with large bulk ink loaders

  • Easily manage ink levels with new indicator LED lights and unified ink loaders on one side of the printer

  • Increased roll feed stability with new upgraded media feed flanges

  • Keep large print jobs wound tightly to core with new 40kg continuous torque take-up with selectable high or low torque settings

  • Maximize print head life with new True Traffic Color spot ink configuration using two channels for black, allowing the print load to be split between two channels

Improved Operator Experience

The operator experience is part of what sets the TrafficJet Xpert apart from other digital print systems. New features designed to simplify operation and avoid downtime will reduce headaches and increase output.

  • Monitor prints in real-time with large clear front panel design

  • Easily inspect print quality with new illuminated interior when panel opened

  • Minimized dust intrusion with tighter front panel tolerances

  • Reduced wear and potential clogging with simplified ink supply lines and removal of adapters

  • Simple access to print carriage and maintenance station with single front panel design

  • Reduced downtime from service calls with automatic print head alignment

  • Save ink with new individual print head cleaning modes

  • Quicker troubleshooting with more user-replaceable parts
Built-in Graffiti Cleanability
With OL-1000 protective overlay

Unmatched Durability from Avery Dennison

Don’t replace your signs, clean your signs. Agencies can benefit from reduced replacement costs with traffic signs printed on the TrafficJet Print System. Advanced protective overlay prevents markings from penetrating past the surface, while UV inhibitors increase the sign’s life. This technology offers dependability and reassurance unrivaled by other digital sign printers. Graffiti protection and industry-leading warranties raise the bar for traffic signs. Avery Dennison is the only sheeting manufacturer who offers this standard with every TrafficJet printer.

Complete Print System

The TrafficJet Print System is a complete traffic sign production process designed and supported by Avery Dennison technical personnel. Every purchase of a TrafficJet Xpert includes professional on-site installation and training, as well as a custom FlexiPRINT Avery Dennison Edition software.

Specifications



Print method Drop-on demand, piezo drive method
Number of nozzles (180 × 8 rows) × 2 staggered heads
Ink type TrafficJet™ Eco-Solvent spot colors & Cyan and Magenta
Variable dot Yes
Minimum droplet size 3.5pL
Print modes 1440/720/540/360dpi 10 + modes
Color configuration True Traffic Color™ spot inks
Number of print heads 2
Maximum print speed / resolution 1,012 square feet/hr (94 square meters/hour)
Maximum resolution 1440dpi
Typical resolution
720x720dpi
Traffic sign print speed Up to 162 square feet/hr
Head height Low: 1.5mm / medium: 2.5mm / high: 4.0mm
Maximum media width 64" (162,56cm)
Maximum print width 63.6" (161,54cm)
Maximum media roll weight 66 lbs (29,93kg)
Media roll diameter / core 6" (15,24cm) maximum / cores 3" (7,62cm) or 2" (5,08cm)
Take-up system Standard
Media auto cut Standard
Software FlexiPRINT Avery Dennison Edition
Power requirements Voltage: AC 100V~120V ±10% / AC 200V~240V ±10%
Operating temperature 68°F–89.6°F
Operating humidity range 40%–60%
Dimensions (cover closed):
Cover opened:
When installing ink bag cases:
108" (274,32cm) × 35" (88,9cm) × 56" (147,32cm)
108" (274,32cm)
× 35" (88,9cm) × 60" (152,4cm)
108" (274,32cm)
× 35" (88,9cm) × 63.5" (161,29cm)
Dimensions (shipping info) 114" (289,56cm) × 46" (116,84cm) × 51" (129,54cm)
Weight (printer) Printer: 322lbs (146kg) / stand: 70.5lbs (32kg)
Limited Warranty 1 year
